7.0-inch 1024X600 TFT LCD RGB Interface screen module
Model：UE070WS-RB40-L038
1) Pixel Arrangement：RGB Vertical Stripe
2) Interface Mode： LVDS
3) Driver IC： HX8282
4) Operation Temperature：-10~50℃
5) Storage Temperature：-20~60℃
6) Backlight Type：White LED
7) Display mode： Normally Black
8) Pixel Density: 170 PPI
9) LED life time：30,000 Hours
| Size | 7.0Inch |
|---|---|
| Resolution | 1024(W)*600(H) |
| Model | UE070WS-RB40-L038 |
| Type | IPS |
| Active Area | 154.21(W)*85.92(H) |
| Outline | 164.86(W)*99.96(H)*3.5(D) |
| Brightness | 400 cd/㎡ |
| Viewing Angle | All O’clock |
| Interface | RGB |
| Operating Temperature | -10 ~ 50°C |
| Touch Screen | N |
| Display Color | 16.7M Colors |
